DJI Enterprise
DJI Mavic 3E
A portable mapping aircraft for site documentation and photogrammetry.
Built for your operation
The aircraft. The training.
The confidence to put it to work.
A portable mapping aircraft for site documentation and photogrammetry.
- Wide camera: 20 MP with a 4/3-inch sensor and mechanical shutter.
- Telephoto camera: 12 MP.
- DJI maximum flight time: 45 minutes with the standard Intelligent Flight Battery and enterprise propellers, in windless test conditions.
- Supports an optional RTK module; final accessories must be confirmed.
Pair your aircraft with handover or application training scoped to your team and the work you need to do.
DJI specifications and test conditions
Technical data
Full specifications
Aircraft, sensors, controller, power system and compatible accessories. Optional equipment is listed separately from the final supply package.
DJI specification snapshot · Checked 22 October 2026. Maximum flight times and transmission ranges are manufacturer test results. Conditions, payload, battery, firmware and regional rules affect operation. DJI specifications and test conditions ↗
Aircraft
- Weight (with propellers, without accessories) [1]
- DJI Mavic 3E: 915 g
- Max Takeoff Weight
- DJI Mavic 3E/3T/3TA: 1050 g * With DJI Mavic 3 Enterprise Series Battery (EU C1 Version) and DJI Mavic 3 Enterprise Series Low-Noise Propellers, the max takeoff weight of DJI Mavic 3E/3T/3TA is 899 g. ** Note: A Mavic 3 Enterprise Series drone with a C2 label cannot be considered C1-compliant if used with an EU-C1 version battery.
- Dimensions
- Folded (without propellers): 221×96.3×90.3 mm (L×W×H) Unfolded (without propellers): 347.5×283×107.7 mm (L×W×H)
- Diagonal Distance
- 380.1 mm
- Max Ascent Speed
- 6 m/s (Normal Mode) 8 m/s (Sport Mode)
- Max Descent Speed
- 6 m/s (Normal Mode) 6 m/s (Sport Mode)
- Max Flight Speed (at sea level, no wind)
- 15 m/s (Normal Mode) Forward: 21 m/s, Side: 20 m/s, Backward: 19 m/s (Sport Mode) [2]
- Max Wind Speed Resistance
- 12 m/s [3]
- Max Take-off Altitude Above Sea Level
- 6000 m (without payload)
- Max Flight Time (no wind)
- 45 minutes [4] (with DJI Mavic 3 Series Intelligent Flight Battery and DJI Mavic 3 Enterprise Series Propellers) 36 minutes (with DJI Mavic 3 Enterprise Series Battery (EU C1 Version) and DJI Mavic 3 Enterprise Series Low-Noise Propellers) Note: A Mavic 3 Enterprise Series drone with a C2 label cannot be considered C1-compliant if used with an EU-C1 version battery.
- Max Hovering Time (no wind)
- 38 minutes (with DJI Mavic 3 Series Intelligent Flight Battery and DJI Mavic 3 Enterprise Series Propellers) 30 minutes (with DJI Mavic 3 Enterprise Series Battery (EU C1 Version) and DJI Mavic 3 Enterprise Series Low-Noise Propellers) Note: A Mavic 3 Enterprise Series drone with a C2 label cannot be considered C1-compliant if used with an EU-C1 version battery.
- Max Flight Distance
- 32 km (with DJI Mavic 3 Series Intelligent Flight Battery and DJI Mavic 3 Enterprise Series Propellers) 24 km (with DJI Mavic 3 Enterprise Series Battery (EU C1 Version) and DJI Mavic 3 Enterprise Series Low-Noise Propellers) Note: A Mavic 3 Enterprise Series drone with a C2 label cannot be considered C1-compliant if used with an EU-C1 version battery.
- Max Pitch Angle
- 30° (Normal Mode) 35° (Sport Mode)
- Max Angular Velocity
- 200°/s
- GNSS
- GPS+Galileo+BeiDou+GLONASS (GLONASS is supported only when the RTK module is enabled)
- Hovering Accuracy
- Vertical: ±0.1 m (with Vision System); ±0.5 m (with GNSS); ±0.1 m (with RTK) Horizontal: ±0.3 m (with Vision System); ±0.5 m (with High-Precision Positioning System); ±0.1 m (with RTK)
- Operating Temperature Range
- -10° to 40° C (14° to 104° F)
- Internal Storage
- N/A
- Motor Model
- 2008
- Propeller Model
- 9453F Propellers for Enterprise
- Beacon
- Built into the aircraft
- Class
- C2 (EU)
Wide Camera
- Sensor
- DJI Mavic 3E: 4/3 CMOS, Effective pixels: 20 MP
- Lens
- DJI Mavic 3E: FOV: 84° Equivalent Focal Length: 24mm Aperture: f/2.8-f/11 Focus: 1 m to ∞
- ISO Range
- DJI Mavic 3E: 100-6400
- Shutter Speed
- DJI Mavic 3E: Electronic Shutter: 8-1/8000 s Mechanical Shutter: 8-1/2000 s
- Max Image Size
- DJI Mavic 3E: 5280×3956
- Still Photography Modes
- DJI Mavic 3E: Single: 20 MP Timed: 20 MP JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s JPEG+RAW: 3/5/7/10/15/20/30/60 s Smart Low-light Shooting: 20 MP Panorama: 20 MP (raw image)
- Video Resolution
- H.264 4K: 3840×2160@30fps FHD: 1920×1080@30fps
- Bitrate
- DJI Mavic 3E: 4K: 130 Mbps FHD: 70 Mbps
- Supported File Formats
- exFAT
- Photo Format
- DJI Mavic 3E: JPEG/DNG (RAW)
- Video Format
- MP4 (MPEG-4 AVC/H.264)
Tele Camera
- Sensor
- 1/2-inch CMOS, Effective pixels: 12 MP
- Lens
- FOV: 15° Equivalent Focal Length: 162mm Aperture: f/4.4 Focus: 3 m to ∞
- ISO Range
- DJI Mavic 3E: 100-6400
- Shutter Speed
- Electronic Shutter: 8-1/8000 s
- Max Image Size
- 4000×3000
- Photo Format
- JPEG
- Video Format
- MP4 (MPEG-4 AVC/H.264)
- Still Photography Modes
- DJI Mavic 3E: Single: 12 MP Timed: 12 MP JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s Smart Low-light Shooting: 12 MP
- Video Resolution
- H.264 4K: 3840×2160@30fps FHD: 1920×1080@30fps
- Bitrate
- DJI Mavic 3E: 4K: 130 Mbps FHD: 70 Mbps
- Digital Zoom
- 8x (56x hybrid zoom)
Gimbal
- Stabilization
- 3-axis (tilt, roll, pan)
- Mechanical Range
- DJI Mavic 3E: Tilt: -135° to 100° Roll: -45° to 45° Pan: -27° to 27°
- Controllable Range
- Tilt: -90° to 35° Pan: Not controllable
- Max Control Speed (tilt)
- 100°/s
- Angular Vibration Range
- ±0.007°
Sensing
- Type
- Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft.
- Forward
- Measurement Range: 0.5-20 m Detection Range: 0.5-200 m Effective Sensing Speed: Flight Speed ≤15 m/s FOV: Horizontal 90°, Vertical 103°
- Backward
- Measurement Range: 0.5-16 m Effective Sensing Speed: Flight Speed ≤12 m/s FOV: Horizontal 90°, Vertical 103°
- Lateral
- Measurement Range: 0.5-25 m Effective Sensing Speed: Flight Speed ≤15 m/s FOV: Horizontal 90°, Vertical 85°
- Upward
- Measurement Range: 0.2-10 m Effective Sensing Speed: Flight Speed ≤6 m/s FOV: Front and Back 100°, Left and Right 90°
- Downward
- Measurement Range: 0.3-18 m Effective Sensing Speed: Flight Speed ≤6 m/s FOV: Front and Back 130°, Left and Right 160°
- Operating Environment
- Forward, Backward, Lateral, and Upward: Surface with a clear pattern and adequate lighting (lux >15) Downward: Diffuse reflective surface with diffuse reflectivity>20% (e.g. walls, trees, people) and adequate lighting (lux >15)
Video Transmission
- Video Transmission System
- DJI O3 Enterprise Transmission
- Live View Quality
- Remote Controller: 1080p/30fps
- Operating Frequency [6]
- 2.400-2.4835 GHz 5.725-5.850 GHz
- Max Transmission Distance (unobstructed, free of interference) [7]
- DJI Mavic 3E/3T/3TA: FCC: 15 km CE: 8 km SRRC: 8 km MIC: 8 km
- Max Transmission Distance (Obstructed) [8]
- Strong Interference (dense buildings, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC) Medium Interference (suburban areas, city parks, etc.): 3-9 km (FCC), 3-6 km (CE/SRRC/MIC) Low Interference (open spaces, remote areas, etc.): 9-15 km (FCC), 6-8 km (CE/SRRC/MIC)
- Max Download Speed [9]
- 15 MB/s (with DJI RC Pro Enterprise)
- Latency (depending on environmental conditions and mobile device)
- Approx. 200 ms
- Antenna
- 4 Antennas, 2T4R
- Transmission Power (EIRP)
- 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <33 dBm (FCC), ＜30 dBm (SRRC), <14 dBm (CE)
DJI RC Pro Enterprise
- Video Transmission System
- DJI O3 Enterprise Transmission
- Max Transmission Distance (unobstructed, free of interference) [7]
- FCC: 15 km CE/SRRC/MIC: 8 km
- Video Transmission Operating Frequency [6]
- 2.400-2.4835 GHz 5.725-5.850 GHz
- Antenna
- 4 Antennas, 2T4R
- Video Transmission Transmitter Power (EIRP)
- 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.8 GHz: <33 dBm (FCC), <14 dBm (CE), ＜23 dBm (SRRC)
- Wi-Fi Protocol
- 802.11 a/b/g/n/ac/ax Support 2×2 MIMO Wi-Fi
- Wi-Fi Operating Frequency [6]
- 2.400-2.4835 GHz 5.150-5.250 GHz 5.725-5.850 GHz
- Wi-Fi Transmitter Power (EIRP)
- 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) 5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC) 5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)
- Bluetooth Protocol
- Bluetooth 5.1
- Bluetooth Operating Frequency
- 2.400-2.4835 GHz
- Bluetooth Transmitter Power (EIRP)
- < 10 dBm
- Screen Resolution
- 1920×1080
- Screen Size
- 5.5 inches
- Screen
- 60 fps
- Brightness
- 1,000 nits
- Touchscreen Control
- 10-point multi-touch
- Battery
- Li-ion (5000 mAh @ 7.2 V)
- Charging Type
- Recommended to be charged with the included DJI USB-C Power Adapter (100W) or USB charger at 12 V or 15 V
- Rated Power
- 12 W
- Storage Capacity
- Internal Storage (ROM): 64 GB Supports a microSD card for expanded capacity.
- Charging Time
- Approx. 1 hour 30 minutes (with the included DJI USB-C Power Adapter (100W) only charging the remote controller or a USB charger at 15 V) Approx. 2 hours (with a USB charger at 12 V) Approx. 2 hours 50 minutes (with the included DJI USB-C Power Adapter (100W) charging the aircraft and remote controller simultaneously)
- Operating Time
- Approx. 3 hours
- Video Output Port
- Mini-HDMI port
- Operating Temperature Range
- -10° to 40° C (14° to 104° F)
- Storage Temperature
- -30° to 60° C (-22° to 140° F) (within one month) -30° to 45° C (-22° to 113° F) (one to three months) -30° to 35° C (-22° to 95° F) (three to six months) -30° to 25° C (-22° to 77° F) (more than six months)
- Charging Temperature
- 5° to 40° C (41° to 104° F)
- Supported DJI Aircraft [10]
- DJI Mavic 3E/3T/3TA
- GNSS
- GPS+Galileo+GLONASS
- Dimensions
- Antennas folded and controller sticks unmounted: 183.27×137.41×47.6 mm (L×W×H) Antennas unfolded and controller sticks mounted: 183.27×203.35×59.84 mm (L×W×H)
- Weight
- Approx. 680 g
- Model
- RM510B
Storage
- Supported Memory Cards
- Aircraft: U3/Class10/V30 or above is required. A list of recommended microSD cards can be found below.
- Recommended microSD Cards
- Remote Controller: SanDisk Extreme PRO 64GB V30 A2 microSDXC SanDisk High Endurance 64GB V30 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC SanDisk Extreme 512GB V30 A2 microSDXC Lexar 667x 64GB V30 A2 microSDXC Lexar High-Endurance 64GB V30 microSDXC Lexar High-Endurance 128GB V30 microSDXC Lexar 667x 256GB V30 A2 microSDXC Lexar 512GB V30 A2 microSDXC Samsung EVO Plus 64GB V30 microSDXC Samsung EVO Plus 128GB V30 microSDXC Samsung EVO Plus 256GB V30 microSDXC Samsung EVO Plus 512GB V30 microSDXC Kingston Canvas Go! Plus 128GB V30 A2 microSDXC Kingston Canvas React Plus 128GB V90 A1 microSDXC Aircraft: SanDisk Extreme 32GB V30 A1 microSDHC SanDisk Extreme PRO 32GB V30 A1 microSDHC SanDisk Extreme 512GB V30 A2 microSDXC Lexar 1066x 64GB V30 A2 microSDXC Kingston Canvas Go! Plus 64GB V30 A2 microSDXC Kingston Canvas React Plus 64GB V90 A1 microSDXC Kingston Canvas Go! Plus 128GB V30 A2 microSDXC Kingston Canvas React Plus 128GB V90 A1 microSDXC Kingston Canvas React Plus 256GB V90 A2 microSDXC Samsung PRO Plus 256GB V30 A2 microSDXC
Battery
- Capacity
- DJI Mavic 3 Series Intelligent Flight Battery: 5000 mAh DJI Mavic 3 Enterprise Series Battery (EU C1 Version): 4230 mAh
- Standard Voltage
- 15.4 V
- Max Charging Voltage
- 17.6 V
- Type
- LiPo 4S
- Chemical System
- LiCoO2
- Energy
- DJI Mavic 3 Series Intelligent Flight Battery: 77 Wh DJI Mavic 3 Enterprise Series Battery (EU C1 Version): 65.15 Wh
- Weight
- DJI Mavic 3 Series Intelligent Flight Battery: 335.5 g DJI Mavic 3 Enterprise Series Battery (EU C1 Version): 285 g
- Charging Temperature
- 5° to 40° C (41° to 104° F)
Charger
- Input
- 100-240 V (AC Power), 50-60 Hz, 2.5 A
- Output Power
- 100 W
- Output
- Max. 100 W (total) When both ports are used, the maximum output power of each interface is 82 W, and the charger will dynamically allocate the output power of the two ports according to the load power.
Charging Hub
- Input
- USB-C: 5-20 V, 5.0 A
- Output
- Battery Port: 12-17.6 V, 8.0 A
- Rated Power
- 100 W
- Charging Type
- Three batteries charged in sequence
- Charging Temperature Range
- 5° to 40° C (41° to 104° F)
RTK ModuleOptional / compatible equipment
- Dimensions
- 50.2×40.2×66.2 mm (L×W×H)
- Weight
- 24±2 g
- Interface
- USB-C
- Power
- Approx. 1.2 W
- RTK Positioning Accuracy
- RTK Fix: Horizontal: 1 cm + 1 ppm; Vertical: 1.5 cm + 1 ppm
SpeakerOptional / compatible equipment
- Dimensions
- 114.1×82.0×54.7 mm (L×W×H)
- Weight
- 85±2 g
- Interface
- USB-C
- Rated Power
- 3 W
- Max Volume [11]
- 110 dB @ 1 m
- Effective Broadcast Distance [11]
- 100 m @ 70 dB
- Bit Rate
- 16 Kbps/32 Kbps
- Operating Temperature Range
- -10° to 40° C (14° to 104° F)
Other
- Notes
- 1. The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors. When using the DJI Mavic 3 Enterprise Series Battery (EU C1 Version), the bare weight of the Mavic 3E (with battery, low-noise propellers, and microSD card) is 865 grams, and the Mavic 3T/3TA (with battery, low-noise propellers, and microSD card) is 870 grams. Always verify and comply with local regulations before flight. 2. When using the DJI Mavic 3 Enterprise Series Battery (EU C1 Version), the drone will disable the Attitude Mode to ensure flight speed remains below 19 m/s in windless conditions. 3. Max wind speed resistance during takeoff and landing. 4. Measured by Mavic 3 Enterprise Series flying at a constant speed of 32.4 kph in a windless environment at sea level until the battery reached 0%. Data is for reference only. Please pay attention to the RTH reminder on the DJI Fly app during flight. 5. DO NOT expose the infrared camera lenses to strong sources of energy such as the sun, lava, or a laser beam. Otherwise, the camera sensor may be burned leading to permanent damage. 6. In some countries and regions, the 5.8 and 5.1GHz frequencies are prohibited, or the 5.1GHz frequency is only allowed for indoor use. Check local laws and regulations for more information. 7. Measured in an unobstructed environment free of interference. The above data shows the farthest communication range for one-way, non-return flights (with no payload) under each standard. During your flight, please pay attention to RTH reminder on the DJI Pilot 2 app. 8. Data tested under different standards in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee as to the actual flight distance. 9. Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz. With footage saved on the built-in SSD or the internal storage. Download speeds may vary depending on actual conditions. 10. Will support more DJI aircraft in the future. Visit the official website for the latest information. 11. The data is measured in an experimental environment and is for reference only. The actual situation will be slightly different due to different software versions, sound sources, specific environments, and other conditions. The final result is subject to actual use.
- Guaranteed software updates until
- 2024/12/31
Equipment. Confidence. Capability.
Make the aircraft part of your workflow
Choose support to suit your team’s experience and application.
Aircraft only
Equipment without a training package.
Aircraft + handover
Setup, preflight checks, controller familiarisation and battery care.
Aircraft + application training
Mapping mission setup, overlap and exposure checks, RTK options and data handover.
Training content, prerequisites, location, dates, duration and price are confirmed by quotation. These options do not reserve a course place or grant a licence. Discuss RePL licence training separately.
Enquire about this package
